BUCCANEER 240
Built by Bayliner Marine Corp (USA)
• Designed by Alan Payne/Bayliner
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Dimensions
Length Overall (LOA):
7.21 m
Length Waterline (LWL):
6.20 m
Beam:
2.44 m
Draft (Max):
0.76 m
Max Height:
10.31 m
Weight & Ballast
Displacement:
1,814 kg
Ballast:
567 kg
Sail Plan
Foresail Area:
11.35 m²
Mainsail Area:
9.04 m²
Total Sail Area (calculated):
20.39 m²
Sail Area (reported):
23.04 m²
I (Fore Triangle Height):
7.99 m
J (Fore Triangle Base):
2.84 m
P (Mainsail Hoist):
6.78 m
E (Boom Length):
2.67 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.04 knots
SA/Displacement (Calculated):
13.72
SA/Displacement (Reported):
15.79
Ballast/Disp Ratio:
31.25%
Displacement/Length:
212.52
Comfort Ratio:
18.16
Capsize Screening:
2.02
S-Number:
2.20
Notes
This same yacht, but with a diesel inboard, was called the BUCCANEER 245. It is thought that the hull for the BUCCANEER 200, 210, 240, and 245 all derive from the COLUMBIA T-23.
