BUCCANEER 200
Built by Bayliner Marine Corp (USA)
• Designed by Alan Payne/Bayliner
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Dimensions
Length Overall (LOA):
6.22 m
Length Waterline (LWL):
5.41 m
Beam:
2.44 m
Draft (Max):
0.53 m
Weight & Ballast
Displacement:
953 kg
Ballast:
340 kg
Sail Plan
Foresail Area:
9.11 m²
Mainsail Area:
8.69 m²
Total Sail Area (calculated):
17.80 m²
Sail Area (reported):
17.74 m²
I (Fore Triangle Height):
7.86 m
J (Fore Triangle Base):
2.32 m
P (Mainsail Hoist):
6.71 m
E (Boom Length):
2.59 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
5.65 knots
SA/Displacement (Calculated):
18.37
SA/Displacement (Reported):
18.68
Ballast/Disp Ratio:
35.71%
Displacement/Length:
167.64
Comfort Ratio:
10.96
Capsize Screening:
2.50
S-Number:
3.35
Notes
The hull for the BUCCANEER 200, 210, 240, and 245 all derive from tooling originally used to build the COLUMBIA T-23. (Thanks to Craig Montague for supplying background information on these yachts.)
