BRISTOL 41.1
Built by Bristol Yachts Inc. (USA)
• Designed by Ted Hood
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1981
Last Built:
1994
Number Built:
104
Dimensions
Length Overall (LOA):
12.54 m
Length Waterline (LWL):
10.16 m
Beam:
3.94 m
Draft (Max):
3.05 m
Draft (Min):
1.37 m
Max Height:
17.98 m
Weight & Ballast
Displacement:
12,034 kg
Ballast:
4,763 kg
Sail Plan
Foresail Area:
41.43 m²
Mainsail Area:
31.88 m²
Total Sail Area (calculated):
73.31 m²
Sail Area (reported):
77.11 m²
I (Fore Triangle Height):
16.15 m
J (Fore Triangle Base):
5.13 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
4.65 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Fuel Capacity:
303 L
Water Capacity:
681 L
Performance Ratios
Hull Speed:
7.74 knots
SA/Displacement (Calculated):
13.96
SA/Displacement (Reported):
14.99
Ballast/Disp Ratio:
39.58%
Displacement/Length:
319.88
Comfort Ratio:
38.06
Capsize Screening:
1.74
S-Number:
1.40
Notes
An 'extended' version later became the BRISTOL 43.3.
