ZUANELLI 34
Built by Cantiere Zuanelli (ITA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Dimensions
Length Overall (LOA):
10.50 m
Length Waterline (LWL):
8.42 m
Beam:
3.20 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
5,000 kg
Ballast:
2,200 kg
Sail Plan
Foresail Area:
26.49 m²
Mainsail Area:
20.23 m²
Total Sail Area (calculated):
46.72 m²
Sail Area (reported):
46.73 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
3.95 m
P (Mainsail Hoist):
11.80 m
E (Boom Length):
3.43 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Fuel Capacity:
72 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
7.04 knots
SA/Displacement (Calculated):
15.98
SA/Displacement (Reported):
16.30
Ballast/Disp Ratio:
44.00%
Displacement/Length:
233.55
Comfort Ratio:
25.06
Capsize Screening:
1.89
S-Number:
2.26
Notes
Similar to ALPA 34. (Based on S&S #2242).
