Z 30+
Built by Vaxholm Komposit for Z Yachts (SWE)
• Designed by Johan Larsvall/Jimmy Hellberg/Jacob Vierø
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
Carbon/Composite
First Built:
2021
Dimensions
Length Overall (LOA):
9.35 m
Beam:
3.25 m
Draft (Max):
2.08 m
Weight & Ballast
Displacement:
2,592 kg
Ballast:
1,470 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
23.15 m²
Mainsail Area:
27.66 m²
Total Sail Area (calculated):
50.81 m²
Sail Area (reported):
56.52 m²
I (Fore Triangle Height):
12.10 m
J (Fore Triangle Base):
3.83 m
P (Mainsail Hoist):
12.30 m
E (Boom Length):
4.50 m
Engine & Systems
Engine Type:
Outboard
Performance Ratios
SA/Displacement (Calculated):
26.93
SA/Displacement (Reported):
30.55
Ballast/Disp Ratio:
56.71%
Capsize Screening:
2.39
Notes
Partially built in the Z31's old molds. However, the hull is thoroughly modified and everything else on the boat is completely newly developed.
