YANKEE 26
Built by Yankee Yachts Inc. (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Dimensions
Length Overall (LOA):
7.92 m
Length Waterline (LWL):
6.30 m
Beam:
2.64 m
Draft (Max):
1.45 m
Weight & Ballast
Displacement:
2,420 kg
Ballast:
975 kg
Sail Plan
Foresail Area:
16.03 m²
Mainsail Area:
11.83 m²
Total Sail Area (calculated):
27.86 m²
Sail Area (reported):
27.87 m²
I (Fore Triangle Height):
10.21 m
J (Fore Triangle Base):
3.14 m
P (Mainsail Hoist):
8.63 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
6.09 knots
SA/Displacement (Calculated):
15.46
SA/Displacement (Reported):
15.77
Ballast/Disp Ratio:
40.30%
Displacement/Length:
269.69
Comfort Ratio:
20.84
Capsize Screening:
1.99
S-Number:
1.88
Notes
S&S design #2065.1. Similar to SHE 27 (S&S #2065). After Yankee Yachts went out of business in 1975, additional boats were built by Heritage Boat Works (USA) until 1990. IOR 1/4 ton.
