X-40
Built by X Yachts (DEN)
• Designed by Niels Jeppesen
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG w/Divinycell core
First Built:
2004
Last Built:
2010
Number Built:
140
Dimensions
Length Overall (LOA):
12.19 m
Length Waterline (LWL):
10.71 m
Beam:
3.80 m
Draft (Max):
2.10 m
Weight & Ballast
Displacement:
7,450 kg
Ballast:
3,200 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.26 m²
Mainsail Area:
44.09 m²
Total Sail Area (calculated):
80.35 m²
Sail Area (reported):
89.50 m²
I (Fore Triangle Height):
16.49 m
J (Fore Triangle Base):
4.40 m
P (Mainsail Hoist):
15.75 m
E (Boom Length):
5.60 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
40 HP
Performance Ratios
Hull Speed:
7.94 knots
SA/Displacement (Calculated):
21.06
SA/Displacement (Reported):
23.94
Ballast/Disp Ratio:
42.96%
Displacement/Length:
168.98
Comfort Ratio:
24.08
Capsize Screening:
1.97
S-Number:
3.66
Notes
Shallow draft: 1.80m/5.9'
