X-34
Built by X-Yachts (DEN)
• Designed by Niels Jeppesen
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2007
Last Built:
2013
Number Built:
144
Dimensions
Length Overall (LOA):
10.36 m
Length Waterline (LWL):
9.09 m
Beam:
3.41 m
Draft (Max):
1.90 m
Weight & Ballast
Displacement:
5,300 kg
Ballast:
2,200 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
26.42 m²
Mainsail Area:
32.98 m²
Total Sail Area (calculated):
59.40 m²
Sail Area (reported):
59.46 m²
I (Fore Triangle Height):
14.33 m
J (Fore Triangle Base):
3.69 m
P (Mainsail Hoist):
14.05 m
E (Boom Length):
4.69 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM20C
Engine Power:
20 HP
Fuel Capacity:
79 L
Water Capacity:
197 L
Performance Ratios
Hull Speed:
7.32 knots
SA/Displacement (Calculated):
19.54
SA/Displacement (Reported):
19.96
Ballast/Disp Ratio:
41.51%
Displacement/Length:
196.71
Comfort Ratio:
23.27
Capsize Screening:
1.98
S-Number:
3.08
Notes
Shallow Draft: 1.65m/5.4'
