X-102
Built by X Yachts (DEN)
• Designed by Niels Jeppesen
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1981
Last Built:
1987
Number Built:
173
Dimensions
Length Overall (LOA):
10.03 m
Length Waterline (LWL):
7.80 m
Beam:
3.41 m
Draft (Max):
1.89 m
Weight & Ballast
Displacement:
3,493 kg
Ballast:
1,597 kg
Sail Plan
Foresail Area:
20.21 m²
Mainsail Area:
29.67 m²
Total Sail Area (calculated):
49.88 m²
Sail Area (reported):
49.89 m²
I (Fore Triangle Height):
11.73 m
J (Fore Triangle Base):
3.44 m
P (Mainsail Hoist):
12.89 m
E (Boom Length):
4.60 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM
Fuel Capacity:
45 L
Water Capacity:
95 L
Performance Ratios
Hull Speed:
6.78 knots
SA/Displacement (Calculated):
21.67
SA/Displacement (Reported):
22.10
Ballast/Disp Ratio:
45.71%
Displacement/Length:
205.37
Comfort Ratio:
17.15
Capsize Screening:
2.27
S-Number:
3.18
Notes
The X-102 was winner of the International 3/4 ton cup in 1981 and 1982.
