X BOAT (USA)
Built by Johnson Boat Works (USA)
• Designed by John O. Johnson
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
Construction:
Wood/FG
First Built:
1932
Dimensions
Length Overall (LOA):
4.88 m
Length Waterline (LWL):
4.42 m
Beam:
1.85 m
Draft (Max):
0.79 m
Weight & Ballast
Displacement:
213 kg
Sail Plan
Sail Area (reported):
10.13 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.10 knots
SA/Displacement (Reported):
28.89
Displacement/Length:
68.82
Comfort Ratio:
4.38
Capsize Screening:
3.13
Notes
John O. Johnson was the founder of Johnson Boat works (1897) and was an early innovator in scow design on the Great Lakes. Also called the CUB.
