WITUS 27
Built by Motala Boatyard (SWE)
• Designed by Arvid Laurin
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Fractional (7/8) Sloop
Construction:
FG
First Built:
1970
Number Built:
46
Dimensions
Length Overall (LOA):
8.25 m
Length Waterline (LWL):
6.50 m
Beam:
2.50 m
Draft (Max):
1.20 m
Headroom:
1.80 m
Weight & Ballast
Displacement:
2,700 kg
Ballast:
1,000 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
28.70 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
MD6A
Engine Power:
10 HP
Fuel Capacity:
65 L
Water Capacity:
40 L
Performance Ratios
Hull Speed:
6.19 knots
SA/Displacement (Reported):
15.10
Ballast/Disp Ratio:
37.05%
Displacement/Length:
273.81
Comfort Ratio:
24.19
Capsize Screening:
1.81
Notes
Specifications are from various sources and not confirmed.
