WITTHOLZ 53 (CHEOY LEE)
Built by Cheoy Lee Shipyard Ltd.(HK)
• Designed by Charles Wittholz
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
Construction:
FG w/foam cored deck
First Built:
1977
Dimensions
Length Overall (LOA):
16.15 m
Length Waterline (LWL):
12.50 m
Beam:
4.42 m
Draft (Max):
2.37 m
Weight & Ballast
Displacement:
19,848 kg
Ballast:
8,165 kg
Sail Plan
Foresail Area:
66.43 m²
Mainsail Area:
52.89 m²
Total Sail Area (calculated):
119.32 m²
Sail Area (reported):
119.29 m²
I (Fore Triangle Height):
19.20 m
J (Fore Triangle Base):
6.92 m
P (Mainsail Hoist):
17.53 m
E (Boom Length):
6.04 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4.236 M
Engine Power:
85 HP
Fuel Capacity:
757 L
Water Capacity:
1,136 L
Performance Ratios
Hull Speed:
8.58 knots
SA/Displacement (Calculated):
16.28
SA/Displacement (Reported):
16.62
Ballast/Disp Ratio:
41.14%
Displacement/Length:
283.44
Comfort Ratio:
43.07
Capsize Screening:
1.65
S-Number:
1.85
Notes
Also advertised as CHEOY LEE 53 (1981).
