WINNER 10.10
Built by Winner Yachts
• Designed by Cees van Tongeren
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2005
Number Built:
85
Dimensions
Length Overall (LOA):
10.10 m
Length Waterline (LWL):
8.70 m
Beam:
3.25 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
4,300 kg
Ballast:
1,600 kg
Sail Plan
Foresail Area:
23.04 m²
Mainsail Area:
27.51 m²
Total Sail Area (calculated):
50.55 m²
Sail Area (reported):
50.54 m²
I (Fore Triangle Height):
12.80 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
12.50 m
E (Boom Length):
4.40 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
21 HP
Performance Ratios
Hull Speed:
7.16 knots
SA/Displacement (Calculated):
19.11
SA/Displacement (Reported):
19.50
Ballast/Disp Ratio:
37.20%
Displacement/Length:
182.05
Comfort Ratio:
20.94
Capsize Screening:
2.02
S-Number:
3.23
Notes
Draft:
