WINDSHIP 63
Built by Wellington Boat Co. Inc. (USA)
• Designed by Bill Wellington
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Ketch
Construction:
FG w/airex in hull and balsa deck
First Built:
1982
Dimensions
Length Overall (LOA):
19.25 m
Length Waterline (LWL):
16.46 m
Beam:
5.18 m
Draft (Max):
3.96 m
Draft (Min):
1.75 m
Weight & Ballast
Displacement:
34,019 kg
Ballast:
9,525 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
181.16 m²
Engine & Systems
Engine Make:
Caterpillar
Engine Type:
Diesel
Engine Power:
210 HP
Fuel Capacity:
3,785 L
Water Capacity:
2,271 L
Performance Ratios
Hull Speed:
9.85 knots
SA/Displacement (Reported):
17.63
Ballast/Disp Ratio:
28.00%
Displacement/Length:
212.63
Comfort Ratio:
46.96
Capsize Screening:
1.62
Notes
Also known as the WELLINGTON 63.
