WHITING 36
Built by Various
• Designed by Paul Whiting
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1980
Dimensions
Length Overall (LOA):
10.94 m
Length Waterline (LWL):
9.51 m
Beam:
3.36 m
Draft (Max):
1.95 m
Weight & Ballast
Displacement:
5,580 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.82 m²
Mainsail Area:
35.50 m²
Total Sail Area (calculated):
64.32 m²
Sail Area (reported):
85.79 m²
I (Fore Triangle Height):
13.47 m
J (Fore Triangle Base):
4.28 m
P (Mainsail Hoist):
14.52 m
E (Boom Length):
4.89 m
Engine & Systems
Performance Ratios
Hull Speed:
7.48 knots
SA/Displacement (Calculated):
20.44
SA/Displacement (Reported):
27.82
Displacement/Length:
180.83
Comfort Ratio:
23.86
Capsize Screening:
1.91
S-Number:
3.41
Notes
Sail area:
