WESTWIND 24 (PACESHIP)
Built by Paceship Yachts
• Designed by Ted Hood
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Dimensions
Length Overall (LOA):
7.29 m
Length Waterline (LWL):
5.51 m
Beam:
2.43 m
Draft (Max):
1.68 m
Draft (Min):
0.64 m
Weight & Ballast
Displacement:
2,100 kg
Ballast:
1,075 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
14.77 m²
Mainsail Area:
14.33 m²
Total Sail Area (calculated):
29.10 m²
Sail Area (reported):
28.24 m²
I (Fore Triangle Height):
9.69 m
J (Fore Triangle Base):
3.05 m
P (Mainsail Hoist):
8.75 m
E (Boom Length):
3.28 m
Engine & Systems
Performance Ratios
Hull Speed:
5.70 knots
SA/Displacement (Calculated):
17.75
SA/Displacement (Reported):
17.56
Ballast/Disp Ratio:
51.19%
Displacement/Length:
349.73
Comfort Ratio:
22.76
Capsize Screening:
1.91
S-Number:
1.47
Notes
Also called the PACESHIP P 24.
