WESTERLY 28
Built by Westerly Marine Ltd. (UK)
• Designed by John A. Butler
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1967
Last Built:
1969
Number Built:
40
Dimensions
Length Overall (LOA):
8.61 m
Length Waterline (LWL):
6.71 m
Beam:
2.74 m
Draft (Max):
0.76 m
Weight & Ballast
Displacement:
3,175 kg
Ballast:
1,225 kg
Sail Plan
Sail Area (reported):
35.21 m²
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Power:
7 HP
Fuel Capacity:
38 L
Water Capacity:
57 L
Performance Ratios
Hull Speed:
6.29 knots
SA/Displacement (Reported):
16.62
Ballast/Disp Ratio:
38.57%
Displacement/Length:
293.48
Comfort Ratio:
24.27
Capsize Screening:
1.88
Notes
Also available with triple keel.
