WELLINGTON 47
Built by Wellington Boats Inc. (USA)
• Designed by John G. Alden Inc.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Cutter
Construction:
FG
First Built:
1969
Last Built:
1980
Number Built:
24
Dimensions
Length Overall (LOA):
14.30 m
Length Waterline (LWL):
11.79 m
Beam:
4.11 m
Draft (Max):
2.13 m
Draft (Min):
1.47 m
Weight & Ballast
Displacement:
20,412 kg
Ballast:
4,990 kg
Sail Plan
Sail Area (reported):
103.12 m²
Engine & Systems
Engine Make:
Ford Lehman
Engine Type:
Diesel
Engine Model:
4D254
Engine Power:
185 HP
Fuel Capacity:
1,779 L
Water Capacity:
1,666 L
Performance Ratios
Hull Speed:
8.33 knots
SA/Displacement (Reported):
14.10
Ballast/Disp Ratio:
24.44%
Displacement/Length:
347.41
Comfort Ratio:
52.80
Capsize Screening:
1.52
Notes
Based on the ALDEN ISLANDER 47. (Alden design #1009) Also available as a ketch. SA 1146.
