BREWER 12.8
Built by Ft. Myers Yacht & Ship (USA)
• Designed by Ted Brewer
General Information
Hull Type:
Keel/CB & spade rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
1983
Number Built:
10
Dimensions
Length Overall (LOA):
12.80 m
Length Waterline (LWL):
10.29 m
Beam:
4.11 m
Draft (Max):
2.74 m
Draft (Min):
1.37 m
Weight & Ballast
Displacement:
10,818 kg
Ballast:
4,990 kg
Sail Plan
Foresail Area:
46.50 m²
Mainsail Area:
35.87 m²
Total Sail Area (calculated):
82.37 m²
Sail Area (reported):
82.40 m²
I (Fore Triangle Height):
16.76 m
J (Fore Triangle Base):
5.55 m
P (Mainsail Hoist):
14.26 m
E (Boom Length):
5.03 m
Engine & Systems
Engine Make:
Ford
Engine Type:
Diesel
Engine Power:
90 HP
Fuel Capacity:
424 L
Water Capacity:
757 L
Performance Ratios
Hull Speed:
7.78 knots
SA/Displacement (Calculated):
16.84
SA/Displacement (Reported):
17.20
Ballast/Disp Ratio:
46.12%
Displacement/Length:
276.96
Comfort Ratio:
31.79
Capsize Screening:
1.88
S-Number:
1.95
Notes
The design for the BREWER 12.8 was commissioned by several members of the Knickerbocker Yacht Club of Manhasset Bay, NY. and based on the WHITBY 42.
