BREEHORN 41
Built by Breehorn
• Designed by Simonis-Voogd
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
2006
Dimensions
Length Overall (LOA):
12.40 m
Length Waterline (LWL):
10.48 m
Beam:
3.75 m
Draft (Max):
2.10 m
Draft (Min):
1.75 m
Max Height:
18.30 m
Weight & Ballast
Displacement:
9,300 kg
Ballast:
3,250 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
34.18 m²
Mainsail Area:
39.00 m²
Total Sail Area (calculated):
73.18 m²
Sail Area (reported):
81.20 m²
I (Fore Triangle Height):
15.53 m
J (Fore Triangle Base):
4.40 m
P (Mainsail Hoist):
15.00 m
E (Boom Length):
5.20 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3JH45E
Engine Power:
39 HP
Fuel Capacity:
200 L
Water Capacity:
400 L
Performance Ratios
Hull Speed:
7.86 knots
SA/Displacement (Calculated):
16.55
SA/Displacement (Reported):
18.74
Ballast/Disp Ratio:
34.95%
Displacement/Length:
225.24
Comfort Ratio:
30.89
Capsize Screening:
1.80
S-Number:
2.41
Notes
Shallow draft: 5.74' / 1.75 m
