BREEHORN 37
Built by Breehorn
• Designed by Dick Koopmans Sr..
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1980
Dimensions
Length Overall (LOA):
11.20 m
Length Waterline (LWL):
9.05 m
Beam:
3.54 m
Draft (Max):
1.90 m
Draft (Min):
1.60 m
Max Height:
16.43 m
Weight & Ballast
Displacement:
7,800 kg
Ballast:
3,250 kg
Sail Plan
Foresail Area:
36.03 m²
Mainsail Area:
26.00 m²
Total Sail Area (calculated):
62.03 m²
Sail Area (reported):
71.60 m²
I (Fore Triangle Height):
14.70 m
J (Fore Triangle Base):
4.90 m
P (Mainsail Hoist):
13.33 m
E (Boom Length):
3.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel; Saildrive
Engine Model:
3JH4E
Engine Power:
40 HP
Fuel Capacity:
200 L
Water Capacity:
200 L
Performance Ratios
Hull Speed:
7.30 knots
SA/Displacement (Calculated):
15.77
SA/Displacement (Reported):
18.58
Ballast/Disp Ratio:
41.67%
Displacement/Length:
293.32
Comfort Ratio:
31.90
Capsize Screening:
1.80
S-Number:
1.73
Notes
Thanks to Aike van der Hoeff for providing information on this yacht.
