VINEYARD VIXEN 29
Built by Martha's Vineyard Shipyard (USA)
• Designed by Thomas Hale & Son
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Dimensions
Length Overall (LOA):
9.03 m
Length Waterline (LWL):
7.01 m
Beam:
2.59 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
3,901 kg
Ballast:
1,470 kg
Sail Plan
Foresail Area:
18.27 m²
Mainsail Area:
15.69 m²
Total Sail Area (calculated):
33.96 m²
Sail Area (reported):
33.91 m²
I (Fore Triangle Height):
10.61 m
J (Fore Triangle Base):
3.44 m
P (Mainsail Hoist):
9.36 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Power:
15 HP
Performance Ratios
Hull Speed:
6.43 knots
SA/Displacement (Calculated):
13.70
SA/Displacement (Reported):
13.96
Ballast/Disp Ratio:
37.67%
Displacement/Length:
315.55
Comfort Ratio:
30.74
Capsize Screening:
1.66
S-Number:
1.40
Notes
The VINYARD VIXEN 29 was also available with a yawl rig.
