VIKING 33
Built by Ontario Yachts (CAN)
• Designed by Cuthbertson & Cassian
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Last Built:
1973
Dimensions
Length Overall (LOA):
10.24 m
Length Waterline (LWL):
8.28 m
Beam:
3.00 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
3,995 kg
Ballast:
2,047 kg
Sail Plan
Foresail Area:
29.82 m²
Mainsail Area:
18.44 m²
Total Sail Area (calculated):
48.26 m²
Sail Area (reported):
48.22 m²
I (Fore Triangle Height):
13.05 m
J (Fore Triangle Base):
4.57 m
P (Mainsail Hoist):
11.52 m
E (Boom Length):
3.20 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Performance Ratios
Hull Speed:
6.98 knots
SA/Displacement (Calculated):
19.17
SA/Displacement (Reported):
19.54
Ballast/Disp Ratio:
51.23%
Displacement/Length:
196.02
Comfort Ratio:
22.29
Capsize Screening:
1.91
S-Number:
3.05
Notes
Originally designed with scimitar rudder and shark fin keel.
