VICTORIA 34
Built by Victoria Marine Ltd (UK)
• Designed by C.W. Paine
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1985
Last Built:
2007
Dimensions
Length Overall (LOA):
10.44 m
Length Waterline (LWL):
8.63 m
Beam:
3.24 m
Draft (Max):
1.47 m
Max Height:
14.17 m
Weight & Ballast
Displacement:
5,765 kg
Ballast:
2,506 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
31.75 m²
Mainsail Area:
20.74 m²
Total Sail Area (calculated):
52.49 m²
Sail Area (reported):
52.77 m²
I (Fore Triangle Height):
13.66 m
J (Fore Triangle Base):
4.65 m
P (Mainsail Hoist):
11.83 m
E (Boom Length):
3.51 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3 GM30F
Engine Power:
27 HP
Fuel Capacity:
83 L
Water Capacity:
180 L
Performance Ratios
Hull Speed:
7.13 knots
SA/Displacement (Calculated):
16.33
SA/Displacement (Reported):
16.75
Ballast/Disp Ratio:
43.47%
Displacement/Length:
249.53
Comfort Ratio:
28.04
Capsize Screening:
1.82
S-Number:
2.15
Notes
Also available with a cutter rig with small bow sprit (pictured).
