VANCOUVER 34 PILOT
Built by Northshore Yachts Ltd. (UK)
• Designed by Robert B Harris
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
GRP
First Built:
1994
Last Built:
2005
Number Built:
22
Dimensions
Length Overall (LOA):
10.44 m
Length Waterline (LWL):
8.38 m
Beam:
3.20 m
Draft (Max):
1.45 m
Max Height:
14.17 m
Weight & Ballast
Displacement:
6,350 kg
Ballast:
2,722 kg
Sail Plan
Sail Area (reported):
55.74 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM30F
Engine Power:
27 HP
Fuel Capacity:
151 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
7.03 knots
SA/Displacement (Reported):
16.59
Ballast/Disp Ratio:
42.86%
Displacement/Length:
300.53
Comfort Ratio:
31.98
Capsize Screening:
1.75
Notes
Deck saloon version of the Vancouver 34 Classic.
