VAGABOND 39
Built by Bluewater Yachts Builders Ltd. (TAIWAN)
• Designed by Ron Amy
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1984
Dimensions
Length Overall (LOA):
11.89 m
Length Waterline (LWL):
9.32 m
Beam:
3.51 m
Draft (Max):
1.70 m
Weight & Ballast
Displacement:
10,659 kg
Ballast:
3,992 kg
Sail Plan
Sail Area (reported):
75.25 m²
E (Boom Length):
5.03 m
Engine & Systems
Engine Type:
Diesel
Fuel Capacity:
416 L
Water Capacity:
568 L
Performance Ratios
Hull Speed:
7.41 knots
SA/Displacement (Reported):
15.86
Ballast/Disp Ratio:
37.45%
Displacement/Length:
366.87
Comfort Ratio:
42.42
Capsize Screening:
1.61
Notes
Derived from the LANDFALL 39 when the molds were purchased from Sino American Yachts.
