US 35
Built by US Yachts
• Designed by Stan Huntingford
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
10.74 m
Length Waterline (LWL):
8.69 m
Beam:
3.66 m
Draft (Max):
1.78 m
Headroom:
1.93 m
Max Height:
15.11 m
Weight & Ballast
Displacement:
6,010 kg
Ballast:
2,381 kg
Sail Plan
Foresail Area:
31.70 m²
Mainsail Area:
20.44 m²
Total Sail Area (calculated):
52.14 m²
Sail Area (reported):
52.12 m²
I (Fore Triangle Height):
13.87 m
J (Fore Triangle Base):
4.57 m
P (Mainsail Hoist):
12.19 m
E (Boom Length):
3.35 m
Engine & Systems
Fuel Capacity:
265 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.15 knots
SA/Displacement (Calculated):
15.77
SA/Displacement (Reported):
16.09
Ballast/Disp Ratio:
39.62%
Displacement/Length:
255.52
Comfort Ratio:
24.51
Capsize Screening:
2.03
S-Number:
2.04
Notes
Derived from the COOPER 353.
