UFO 22
Built by UFO Boats (ITA)
• Designed by Umberto Felci
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
Construction:
Composite
First Built:
1998
Dimensions
Length Overall (LOA):
6.60 m
Length Waterline (LWL):
6.60 m
Beam:
2.55 m
Draft (Max):
1.60 m
Draft (Min):
0.50 m
Weight & Ballast
Displacement:
720 kg
Ballast:
288 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.85 m²
Mainsail Area:
14.74 m²
Total Sail Area (calculated):
25.59 m²
Sail Area (reported):
28.43 m²
I (Fore Triangle Height):
7.89 m
J (Fore Triangle Base):
2.75 m
P (Mainsail Hoist):
8.80 m
E (Boom Length):
3.35 m
Engine & Systems
Performance Ratios
Hull Speed:
6.23 knots
SA/Displacement (Calculated):
31.86
SA/Displacement (Reported):
36.06
Ballast/Disp Ratio:
40.01%
Displacement/Length:
69.82
Comfort Ratio:
6.68
Capsize Screening:
2.87
S-Number:
7.42
Notes
Assym. spin. area: 45m2/ sq. ft.
