BOSTROM 31 MKII
• Designed by Bruno Boström/Grandinsson
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1977
Last Built:
1984
Dimensions
Length Overall (LOA):
9.33 m
Length Waterline (LWL):
7.92 m
Beam:
2.76 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
3,300 kg
Ballast:
1,650 kg
Sail Plan
Foresail Area:
20.81 m²
Mainsail Area:
13.58 m²
Total Sail Area (calculated):
34.39 m²
Sail Area (reported):
34.37 m²
I (Fore Triangle Height):
11.40 m
J (Fore Triangle Base):
3.65 m
P (Mainsail Hoist):
9.70 m
E (Boom Length):
2.80 m
Engine & Systems
Engine Make:
Yanmar
Performance Ratios
Hull Speed:
6.83 knots
SA/Displacement (Calculated):
15.52
SA/Displacement (Reported):
15.82
Ballast/Disp Ratio:
50.01%
Displacement/Length:
185.21
Comfort Ratio:
21.81
Capsize Screening:
1.87
S-Number:
2.74
Notes
Same hull as BOSTROM 31 but with more freeboard and new deck.
