TRISS MAGNUM
Built by ABC Fabrikerna (SWE)
• Designed by Lars Hedberg
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1972
Last Built:
1981
Number Built:
450
Dimensions
Length Overall (LOA):
6.00 m
Length Waterline (LWL):
5.20 m
Beam:
2.40 m
Draft (Max):
1.10 m
Weight & Ballast
Displacement:
1,200 kg
Ballast:
560 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
7.59 m²
Mainsail Area:
10.67 m²
Total Sail Area (calculated):
18.26 m²
Sail Area (reported):
18.67 m²
I (Fore Triangle Height):
6.75 m
J (Fore Triangle Base):
2.25 m
P (Mainsail Hoist):
7.90 m
E (Boom Length):
2.70 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Performance Ratios
Hull Speed:
5.53 knots
SA/Displacement (Calculated):
16.17
SA/Displacement (Reported):
16.85
Ballast/Disp Ratio:
46.67%
Displacement/Length:
237.91
Comfort Ratio:
14.67
Capsize Screening:
2.28
S-Number:
2.24
Notes
AKA TRISS 600.
