TRIPP 33
Built by Carroll Marine (USAe 12)
• Designed by Bill Tripp III
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1992
Number Built:
23
Dimensions
Length Overall (LOA):
10.06 m
Length Waterline (LWL):
8.53 m
Beam:
3.15 m
Draft (Max):
2.13 m
Draft (Min):
1.42 m
Weight & Ballast
Displacement:
2,767 kg
Ballast:
1,225 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
20.68 m²
Mainsail Area:
29.52 m²
Total Sail Area (calculated):
50.20 m²
Sail Area (reported):
50.17 m²
I (Fore Triangle Height):
12.19 m
J (Fore Triangle Base):
3.39 m
P (Mainsail Hoist):
12.50 m
E (Boom Length):
4.72 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Model:
2CL
Engine Power:
12 HP
Fuel Capacity:
57 L
Water Capacity:
136 L
Performance Ratios
Hull Speed:
7.09 knots
SA/Displacement (Calculated):
25.47
SA/Displacement (Reported):
25.96
Ballast/Disp Ratio:
44.26%
Displacement/Length:
124.05
Comfort Ratio:
14.25
Capsize Screening:
2.26
S-Number:
5.07
