TRIO 96
Built by Trio Boats (SWE)
• Designed by Hans Blomstergren
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional (7/8) Sloop
Construction:
FG
First Built:
1982
Dimensions
Length Overall (LOA):
9.60 m
Length Waterline (LWL):
7.60 m
Beam:
3.15 m
Draft (Max):
1.75 m
Max Height:
15.50 m
Weight & Ballast
Displacement:
3,900 kg
Ballast:
1,800 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
19.98 m²
Mainsail Area:
24.19 m²
Total Sail Area (calculated):
44.17 m²
Sail Area (reported):
62.00 m²
I (Fore Triangle Height):
11.10 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
12.40 m
E (Boom Length):
3.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM
Engine Power:
15 HP
Performance Ratios
Hull Speed:
6.69 knots
SA/Displacement (Calculated):
17.83
SA/Displacement (Reported):
25.53
Ballast/Disp Ratio:
46.15%
Displacement/Length:
247.73
Comfort Ratio:
22.03
Capsize Screening:
2.02
S-Number:
2.31
Notes
S.A. (reported) = Main + Genoa.
