TRINTELLA IIA
Built by Anne Wever (NED)
• Designed by Van de Stadt
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1968
Last Built:
1974
Number Built:
60
Dimensions
Length Overall (LOA):
10.00 m
Length Waterline (LWL):
7.32 m
Beam:
2.80 m
Draft (Max):
1.14 m
Weight & Ballast
Displacement:
4,350 kg
Ballast:
2,000 kg
Sail Plan
Foresail Area:
23.44 m²
Mainsail Area:
20.63 m²
Total Sail Area (calculated):
44.07 m²
Sail Area (reported):
51.56 m²
I (Fore Triangle Height):
12.67 m
J (Fore Triangle Base):
3.70 m
P (Mainsail Hoist):
11.15 m
E (Boom Length):
3.70 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD2B
Performance Ratios
Hull Speed:
6.57 knots
SA/Displacement (Calculated):
16.54
SA/Displacement (Reported):
19.74
Ballast/Disp Ratio:
45.97%
Displacement/Length:
309.31
Comfort Ratio:
29.02
Capsize Screening:
1.73
S-Number:
1.67
Notes
Based on VDS design #140.
