TRINTELLA 42
Built by Anne Wever (NED)
• Designed by E. G. van de Stadt
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1981
Last Built:
1989
Number Built:
42
Dimensions
Length Overall (LOA):
12.90 m
Length Waterline (LWL):
10.60 m
Beam:
4.02 m
Draft (Max):
1.95 m
Weight & Ballast
Displacement:
9,000 kg
Ballast:
4,000 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
46.18 m²
Mainsail Area:
38.15 m²
Total Sail Area (calculated):
84.33 m²
Sail Area (reported):
84.36 m²
I (Fore Triangle Height):
17.50 m
J (Fore Triangle Base):
5.28 m
P (Mainsail Hoist):
15.51 m
E (Boom Length):
4.92 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD21
Engine Power:
61 HP
Fuel Capacity:
197 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.90 knots
SA/Displacement (Calculated):
19.49
SA/Displacement (Reported):
19.90
Ballast/Disp Ratio:
44.44%
Displacement/Length:
210.55
Comfort Ratio:
26.67
Capsize Screening:
1.95
S-Number:
2.89
Notes
Rig dimensions from sample IMS certificate.
