BOOTHBAY CHALLENGER (ALDEN)
Built by Hodgdon Bros. (USA)
• Designed by John G. Alden & Assoc,
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Ketch
Construction:
FG
First Built:
1968
Last Built:
1976
Number Built:
14
Dimensions
Length Overall (LOA):
17.86 m
Length Waterline (LWL):
12.50 m
Beam:
4.62 m
Draft (Max):
3.73 m
Draft (Min):
1.62 m
Weight & Ballast
Displacement:
24,176 kg
Ballast:
5,352 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
142.51 m²
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
6-354
Engine Power:
115 HP
Fuel Capacity:
1,514 L
Water Capacity:
1,893 L
Performance Ratios
Hull Speed:
8.58 knots
SA/Displacement (Reported):
17.41
Ballast/Disp Ratio:
22.14%
Displacement/Length:
345.25
Comfort Ratio:
47.62
Capsize Screening:
1.62
Notes
Alden design #1011. Available with a center or aft cockpit though most were delivered with the former. The design also features tandem centerboards.
