BOMBAY PILOTHOUSE 31
Built by New Bombay Trading Co. (USA)
• Designed by Walter Scott
General Information
Hull Type:
Long keel w/rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Dimensions
Length Overall (LOA):
9.45 m
Length Waterline (LWL):
7.80 m
Beam:
3.35 m
Draft (Max):
1.07 m
Headroom:
1.98 m
Max Height:
12.80 m
Weight & Ballast
Displacement:
4,649 kg
Ballast:
1,542 kg
Sail Plan
Foresail Area:
17.85 m²
Mainsail Area:
17.01 m²
Total Sail Area (calculated):
34.86 m²
Sail Area (reported):
38.93 m²
I (Fore Triangle Height):
11.37 m
J (Fore Triangle Base):
3.14 m
P (Mainsail Hoist):
9.54 m
E (Boom Length):
3.57 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2QM15G
Engine Power:
15 HP
Fuel Capacity:
114 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
6.78 knots
SA/Displacement (Calculated):
12.51
SA/Displacement (Reported):
14.26
Ballast/Disp Ratio:
33.17%
Displacement/Length:
273.38
Comfort Ratio:
23.88
Capsize Screening:
2.03
S-Number:
1.56
