TARTAN 26
Built by Tartan Marine (USA)
• Designed by Tom Norton
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Last Built:
1973
Number Built:
73
Dimensions
Length Overall (LOA):
7.92 m
Length Waterline (LWL):
6.86 m
Beam:
2.44 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
2,359 kg
Ballast:
1,043 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
17.63 m²
Mainsail Area:
12.36 m²
Total Sail Area (calculated):
29.99 m²
Sail Area (reported):
30.01 m²
I (Fore Triangle Height):
10.06 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
2.90 m
Engine & Systems
Engine Make:
Kermath (gas) or OB
Engine Type:
Gas
Fuel Capacity:
45 L
Performance Ratios
Hull Speed:
6.36 knots
SA/Displacement (Calculated):
16.92
SA/Displacement (Reported):
17.27
Ballast/Disp Ratio:
44.23%
Displacement/Length:
203.80
Comfort Ratio:
21.38
Capsize Screening:
1.85
S-Number:
2.69
Notes
Thanks to Tartan 26 owner Tod Mills for providing updated information and photo.
