TARTAN 245
Built by Tartan Marine
• Designed by Tim Jackett
General Information
Hull Type:
Lifting keel w/bulb; spade rudder
Rigging Type:
Fractional Sloop
Construction:
Modified epoxy E-glass laminate
First Built:
2019
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
6.76 m
Beam:
2.57 m
Draft (Max):
1.37 m
Draft (Min):
0.51 m
Weight & Ballast
Displacement:
1,247 kg
Ballast:
408 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
11.91 m²
Mainsail Area:
13.39 m²
Total Sail Area (calculated):
25.30 m²
Sail Area (reported):
25.34 m²
I (Fore Triangle Height):
9.20 m
J (Fore Triangle Base):
2.59 m
P (Mainsail Hoist):
8.79 m
E (Boom Length):
3.05 m
Engine & Systems
Performance Ratios
Hull Speed:
6.31 knots
SA/Displacement (Calculated):
21.84
SA/Displacement (Reported):
22.29
Ballast/Disp Ratio:
32.73%
Displacement/Length:
112.66
Comfort Ratio:
10.95
Capsize Screening:
2.41
S-Number:
4.80
