TANZER 29
Built by Tanzer Industries Ltd. (CAN)
• Designed by Joubert/Nivelt
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1986
Dimensions
Length Overall (LOA):
8.84 m
Length Waterline (LWL):
7.39 m
Beam:
3.12 m
Draft (Max):
1.60 m
Max Height:
12.65 m
Weight & Ballast
Displacement:
2,948 kg
Ballast:
1,100 kg
Sail Plan
Foresail Area:
20.27 m²
Mainsail Area:
15.88 m²
Total Sail Area (calculated):
36.15 m²
Sail Area (reported):
37.44 m²
I (Fore Triangle Height):
11.72 m
J (Fore Triangle Base):
3.46 m
P (Mainsail Hoist):
10.25 m
E (Boom Length):
3.10 m
Engine & Systems
Performance Ratios
Hull Speed:
6.60 knots
SA/Displacement (Calculated):
17.58
SA/Displacement (Reported):
18.57
Ballast/Disp Ratio:
37.31%
Displacement/Length:
203.48
Comfort Ratio:
17.63
Capsize Screening:
2.20
S-Number:
2.77
Notes
Shoal draft version:
