TANZER 28
Built by Tanzer Industries Ltd. (CAN)
• Designed by Johann Tanzer
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1972
Dimensions
Length Overall (LOA):
8.41 m
Length Waterline (LWL):
7.16 m
Beam:
2.99 m
Draft (Max):
1.24 m
Max Height:
11.58 m
Weight & Ballast
Displacement:
2,948 kg
Ballast:
1,089 kg
Sail Plan
Foresail Area:
20.10 m²
Mainsail Area:
13.01 m²
Total Sail Area (calculated):
33.11 m²
Sail Area (reported):
32.14 m²
I (Fore Triangle Height):
10.49 m
J (Fore Triangle Base):
3.83 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
3.05 m
Engine & Systems
Performance Ratios
Hull Speed:
6.50 knots
SA/Displacement (Calculated):
16.10
SA/Displacement (Reported):
15.94
Ballast/Disp Ratio:
36.92%
Displacement/Length:
223.59
Comfort Ratio:
19.38
Capsize Screening:
2.11
S-Number:
2.38
Notes
Photo courtesy Adam Hunt.
