TANZER 26
Built by Tanzer Industries Ltd. (CAN)
• Designed by Johann Tanzer
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Last Built:
1985
Number Built:
960
Dimensions
Length Overall (LOA):
8.03 m
Length Waterline (LWL):
6.86 m
Beam:
2.64 m
Draft (Max):
1.17 m
Max Height:
10.06 m
Weight & Ballast
Displacement:
1,973 kg
Ballast:
885 kg
Sail Plan
Foresail Area:
14.82 m²
Mainsail Area:
12.02 m²
Total Sail Area (calculated):
26.84 m²
Sail Area (reported):
26.20 m²
I (Fore Triangle Height):
9.19 m
J (Fore Triangle Base):
3.22 m
P (Mainsail Hoist):
7.70 m
E (Boom Length):
3.12 m
Engine & Systems
Performance Ratios
Hull Speed:
6.36 knots
SA/Displacement (Calculated):
17.06
SA/Displacement (Reported):
16.98
Ballast/Disp Ratio:
44.83%
Displacement/Length:
170.49
Comfort Ratio:
16.00
Capsize Screening:
2.13
S-Number:
3.13
Notes
Most 26s were outboard-powered, though an inboard Yanmar diesel was an option.
