SYMPHONIE 32 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Philippe Briand
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG/balsa cored deck
First Built:
1979
Last Built:
1983
Number Built:
320
Dimensions
Length Overall (LOA):
9.75 m
Length Waterline (LWL):
8.15 m
Beam:
3.28 m
Draft (Max):
1.88 m
Weight & Ballast
Displacement:
4,445 kg
Ballast:
2,000 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
26.34 m²
Mainsail Area:
18.11 m²
Total Sail Area (calculated):
44.45 m²
Sail Area (reported):
44.50 m²
I (Fore Triangle Height):
12.85 m
J (Fore Triangle Base):
4.10 m
P (Mainsail Hoist):
11.15 m
E (Boom Length):
3.25 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Fuel Capacity:
64 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.93 knots
SA/Displacement (Calculated):
16.44
SA/Displacement (Reported):
16.79
Ballast/Disp Ratio:
45.00%
Displacement/Length:
228.56
Comfort Ratio:
22.61
Capsize Screening:
2.01
S-Number:
2.36
Notes
Based on an IOR 3/4 ton prototype.
