SYDNEY 38
Built by Sydney Yachts
• Designed by Murray Burns Dovell
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
Composite
First Built:
1999
Number Built:
65
Dimensions
Length Overall (LOA):
11.73 m
Length Waterline (LWL):
10.75 m
Beam:
3.76 m
Draft (Max):
2.64 m
Weight & Ballast
Displacement:
5,561 kg
Ballast:
1,930 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
35.88 m²
Mainsail Area:
42.33 m²
Total Sail Area (calculated):
78.21 m²
Sail Area (reported):
78.22 m²
I (Fore Triangle Height):
15.95 m
J (Fore Triangle Base):
4.50 m
P (Mainsail Hoist):
15.40 m
E (Boom Length):
5.50 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
38 HP
Fuel Capacity:
95 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
7.96 knots
SA/Displacement (Calculated):
24.92
SA/Displacement (Reported):
25.43
Ballast/Disp Ratio:
34.71%
Displacement/Length:
124.75
Comfort Ratio:
18.43
Capsize Screening:
2.14
S-Number:
4.98
