SWIFTSURE 33 (RHODES)
Built by deVries Lentch, Inc. / Royal Netherlands Aircraft
• Designed by Philip Rhodes
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1959
Last Built:
1965
Number Built:
150
Dimensions
Length Overall (LOA):
10.08 m
Length Waterline (LWL):
6.99 m
Beam:
3.05 m
Draft (Max):
2.01 m
Draft (Min):
1.07 m
Weight & Ballast
Displacement:
5,216 kg
Ballast:
1,542 kg
Sail Plan
Foresail Area:
23.15 m²
Mainsail Area:
23.34 m²
Total Sail Area (calculated):
46.49 m²
Sail Area (reported):
46.64 m²
I (Fore Triangle Height):
11.80 m
J (Fore Triangle Base):
3.92 m
P (Mainsail Hoist):
10.42 m
E (Boom Length):
4.48 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
106 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
6.42 knots
SA/Displacement (Calculated):
15.46
SA/Displacement (Reported):
15.82
Ballast/Disp Ratio:
29.57%
Displacement/Length:
426.39
Comfort Ratio:
31.87
Capsize Screening:
1.78
S-Number:
0.95
Notes
Rhodes Design #692
