SWEDEN YACHTS 70
Built by Sweden Yachts
• Designed by Peter Norlin / Jens Östmann
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
1994
Last Built:
1997
Number Built:
3
Dimensions
Length Overall (LOA):
21.25 m
Length Waterline (LWL):
16.00 m
Beam:
5.18 m
Draft (Max):
2.60 m
Weight & Ballast
Displacement:
31,000 kg
Ballast:
11,000 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
93.32 m²
Mainsail Area:
98.53 m²
Total Sail Area (calculated):
191.85 m²
Sail Area (reported):
191.84 m²
I (Fore Triangle Height):
24.99 m
J (Fore Triangle Base):
7.47 m
P (Mainsail Hoist):
24.71 m
E (Boom Length):
7.97 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
TAMD 41D
Engine Power:
170 HP
Fuel Capacity:
1,200 L
Water Capacity:
1,499 L
Performance Ratios
Hull Speed:
9.71 knots
SA/Displacement (Calculated):
19.44
SA/Displacement (Reported):
19.86
Ballast/Disp Ratio:
35.48%
Displacement/Length:
210.97
Comfort Ratio:
42.15
Capsize Screening:
1.67
S-Number:
2.89
