SWARBRICK 80
Built by Swarbrick Brothers (AUS)
• Designed by Kim Swarbrick
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1978
Dimensions
Length Overall (LOA):
8.00 m
Length Waterline (LWL):
7.10 m
Beam:
2.70 m
Draft (Max):
1.40 m
Weight & Ballast
Displacement:
1,400 kg
Ballast:
550 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.68 m²
Mainsail Area:
17.06 m²
Total Sail Area (calculated):
29.74 m²
Sail Area (reported):
29.73 m²
I (Fore Triangle Height):
8.75 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
9.75 m
E (Boom Length):
3.50 m
Engine & Systems
Performance Ratios
Hull Speed:
6.47 knots
SA/Displacement (Calculated):
23.76
SA/Displacement (Reported):
24.22
Ballast/Disp Ratio:
39.31%
Displacement/Length:
109.05
Comfort Ratio:
10.79
Capsize Screening:
2.44
S-Number:
5.17
