SWAN 90 FD
Built by Nautor
• Designed by German Frers
General Information
Hull Type:
Lifting Keel
Rigging Type:
Masthead Sloop
Construction:
Carbon Composite
First Built:
2007
Number Built:
12
Dimensions
Length Overall (LOA):
27.10 m
Length Waterline (LWL):
24.55 m
Beam:
6.46 m
Draft (Max):
4.40 m
Draft (Min):
3.00 m
Weight & Ballast
Displacement:
58,967 kg
Ballast:
18,370 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
197.97 m²
Mainsail Area:
203.26 m²
Total Sail Area (calculated):
401.23 m²
Sail Area (reported):
401.25 m²
I (Fore Triangle Height):
36.80 m
J (Fore Triangle Base):
10.76 m
P (Mainsail Hoist):
35.50 m
E (Boom Length):
11.45 m
Engine & Systems
Engine Make:
VW
Engine Type:
Diesel
Engine Power:
285 HP
Fuel Capacity:
1,628 L
Water Capacity:
999 L
Performance Ratios
Hull Speed:
12.03 knots
SA/Displacement (Calculated):
26.48
SA/Displacement (Reported):
27.07
Ballast/Disp Ratio:
31.15%
Displacement/Length:
111.09
Comfort Ratio:
41.49
Capsize Screening:
1.68
S-Number:
5.51
