BOLERO 35.5
Built by Production Yachts Ltd
• Designed by David Thomas
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1979
Last Built:
1981
Number Built:
6
Dimensions
Length Overall (LOA):
10.82 m
Length Waterline (LWL):
8.97 m
Beam:
3.45 m
Draft (Max):
1.92 m
Weight & Ballast
Displacement:
5,490 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.24 m²
Mainsail Area:
31.90 m²
Total Sail Area (calculated):
53.14 m²
Sail Area (reported):
53.14 m²
I (Fore Triangle Height):
11.38 m
J (Fore Triangle Base):
3.73 m
P (Mainsail Hoist):
13.10 m
E (Boom Length):
4.87 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD20
Engine Power:
25 HP
Fuel Capacity:
61 L
Performance Ratios
Hull Speed:
7.27 knots
SA/Displacement (Calculated):
17.08
SA/Displacement (Reported):
17.42
Displacement/Length:
212.19
Comfort Ratio:
23.61
Capsize Screening:
1.98
S-Number:
2.61
Notes
Derived for an IOR 1 ton design.
