SWAN 68
Built by Nautor
• Designed by German Frers
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1992
Last Built:
2004
Number Built:
24
Dimensions
Length Overall (LOA):
20.63 m
Length Waterline (LWL):
16.68 m
Beam:
5.42 m
Draft (Max):
3.30 m
Weight & Ballast
Displacement:
40,000 kg
Ballast:
16,000 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
108.28 m²
Mainsail Area:
92.75 m²
Total Sail Area (calculated):
201.03 m²
Sail Area (reported):
201.04 m²
I (Fore Triangle Height):
27.43 m
J (Fore Triangle Base):
7.89 m
P (Mainsail Hoist):
24.84 m
E (Boom Length):
7.47 m
Engine & Systems
Performance Ratios
Hull Speed:
9.91 knots
SA/Displacement (Calculated):
17.19
SA/Displacement (Reported):
17.56
Ballast/Disp Ratio:
40.00%
Displacement/Length:
240.27
Comfort Ratio:
50.36
Capsize Screening:
1.60
S-Number:
2.32
Notes
Also available with a traditional counter. See SWAN 68 (TRAD).
