SWAN 61
Built by Nautor
• Designed by German Frers
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1985
Last Built:
1990
Number Built:
14
Dimensions
Length Overall (LOA):
18.44 m
Length Waterline (LWL):
14.68 m
Beam:
5.00 m
Draft (Max):
2.95 m
Weight & Ballast
Displacement:
27,669 kg
Ballast:
9,208 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
85.41 m²
Mainsail Area:
68.42 m²
Total Sail Area (calculated):
153.83 m²
Sail Area (reported):
153.85 m²
I (Fore Triangle Height):
24.26 m
J (Fore Triangle Base):
7.04 m
P (Mainsail Hoist):
21.79 m
E (Boom Length):
6.28 m
Engine & Systems
Performance Ratios
Hull Speed:
9.30 knots
SA/Displacement (Calculated):
16.82
SA/Displacement (Reported):
17.18
Ballast/Disp Ratio:
33.28%
Displacement/Length:
243.95
Comfort Ratio:
43.77
Capsize Screening:
1.67
S-Number:
2.25
Notes
Reverse or traditional counter.
